Can be universally employed as either an air, fluid or sandbath for heating many of the various receptacles in laboratory use, regardless of size or material, for temperatures ranging between 60...600°C. Construction: Conical bath tank with 2L capacity for MU85 made of stainless steel with stainless steel tubular heating element. Upper shell fire enameled. Stainless steel substructure
Controllability of type MU85/ER, MS26/E As MU85 but with an additional built-in electronic switching relay and contactor socket (extra-low voltage) for connection of a contact thermometer, however, this connection is not conditional. If a contact thermometer is connected, it is automatically given priority in the control. Without a contact thermometer, they work in exactly the same way as Type MU85 - with a variable power control
Use as air bath: The low-mass, radiant heater can reach the highest temperature of approx. 800°C in about 5 minutes. The insulated, built-in energy output regulator allows a stage-less calibration of the power from 10...100%, which is equal to a radiated temperature from around 60...600°C.
Use as liquid bath: Because the heating element is completely insulated, the container can be directly filled with e.g. water or oil. Use as sand bath: with the use of stainless steel, sand bath dishes (which can be delivered) the multifunctional heating appliance can also be used as a sand bath.
Use as sand bath: with the use of stainless steel, sand bath dishes (which can be delivered) the multifunctional heating appliance can also be used as a sand bath
Product Type | Heating Bath |
---|---|
Volume | 2 L |
Exterior Dimensions | 205 x 230 x 250 mm |
Voltage Rating | 230 V |
Power Rating | 800 W |
Weight | 2.4 kg |
