The compact and user-friendly Q-Front EDI Pure systems are highly recommended as the pure water source in your laboratory, providing Grade 2 water for a wide range of general laboratory applications. The Q-Front EDI Pure systems purify the incoming feed water by edionization or electrodeionization (EDI) technology. EDI is the most cost-effective long-term solution due to reduced running costs, as no deionization cartridges have to be replaced.
| Product Type | Q-Front EDI Pure Systems |
|---|---|
| Model | Q-Front 5 EDI Pure |
| Grade 2 Water Resistivity at 25 °C | ≥10 to 5 MΩ x cm |
| Grade 2 Water Conductivity at 25 °C | ≤0.1 to 0.2 µS/cm |
| Particles >0.22 μm | < 1/mL |
| Nominal flow, pure water (to storage tank) | 5 L/h |
| Dimensions (WxDxH) | 35 x 39 x 54 cm |
| System Weight | 16 kg |
| Operating Weight | 18 kg |
| TOC Level | < 30 ppb |
| Feed Water | Potable Tap Water |
| Pressure | 0.4 to 6 bar |
| Conductivity | <2000 μS/cm |
| Temperature | 5 to 35 °C |
| Display | Colour LCD |
| Mains Voltage | 200 to 240 VAC |
| Power | 130 W |
| Relative Humidity | 20–80% |
